23
41mm Torpedo
Black Anodize
X23 Trees
41FLAX23-0DT-A
———————————————
Complete Touring Bike Front Ends
•Custom built to your project requirements
•Available with the X – 23 Triple Tree Kit or
Raked Triple Trees for your 23”, 26”, & 30”
Custom Built Big Wheel Bagger
•Features the HHI Billet Lower Leg kit
in Torpedo or Bomber choice of style
finished in Chrome or Black
•Uses stock, Hi Performance Mono Tube Cartridge
or Full Air Ride Shocks
•Single or Dual Caliper Mounts
•Hidden Axle and spacers
•Adjustable HHI Heavy Duty 4 Bolt Fender Mounts
Complete Front Ends
HHI offers a comprehensive line of front end suspension
products in a 41mm conventional fork. Front ends are
available with HHI triple trees offered in various styles,
finishes and rakes. Triple tree widths include both mid and
wide glide. Fork tubes in lengths up to 12" over stock. Fork
assembly use internal dampening components
manufactured to OEM specs or Progressive Monotube
Cartridge. Fork tubes have the OEM hard chrome finish
providing long term seal and bushing life. Lower legs are
offered in a variety of styles and finishes allowing us to
build the front end of your choice. Choose the
combination that is best suited for your project.
External Fork Stop for FXR, Dyna, XL only
(EFS)
Tube Length in Inches Over Stock FXST:
(0)
,
(2)
,
(4)
,
(6)
,
(8)
,
(10)
,
(12)
Brake Setup: Single
(S)
or Dual
(D)
Fork Leg Style: 41mm: Torpedo
(T)
, Bomber
(B)
2000-up Caliper mount: Leave blank for 99-earlier
(Y2)
Right side Brake: Leave blank for left side single disc
(R)
-
(41)
mm
-
(WG)
Wide Glide,
(MG)
Mid Glide,
(FL)
Touring,
(FB)
Fatboy/Heritage
-
(C)
Chrome,
(P)
Polish,
(M)
Raw finish or
(A)
Black Anodize
-
(R)
Rake:
(0)
°,
(3)
°,
(5)
°,
(6)
°, and
(7)
° - (WG) & (MG) only
(X23)
,
(7)
°,
(9)
°, and
(12)
° - (FL) only
(4)
°, and
(6)
° - (FB) only
41WGCR3-EFS-12ST-Y2-R
41mm Torpedo Legs,
Chrome Slade Trees
41mm Bomber Legs Chrome Wide Glide Trees
41mm Black Torpedo Legs, Black Wide Glide Trees
